Eminence Legend 1275 - 75W 8ohm

Hover over image to zoom

  • Eminence Legend 1275
  • Eminence Legend 1275
Eminence
C$79.79
SKU:
QC-440-090
Availability:
Special Order. Ships in 1-7 business days.

 Product Description

A British voiced speaker reminiscent of classic OEM tones from the past with tight, punchy lows, warm mids, and crisp, articulate, open highs.

SPECIFICATIONS
Nominal Diameter: 12.0", 304.8 mm
Nominal Impedance: 8 ohms
Power: 75w rms
Freq. Response: 80.0 Hz-5.1 kHz
Sensitivity: 101.1 db 1w/1m
Magnet Weight: 34.0 oz, 964.5 grams
Gap Height 0.313", 8.0 mm
Voice Coil Diameter 1.5", 38 mm

MOUNTING INFORMATION
Acceptable Enclosure Types
- Closed back: Yes
- Open back: Not applicable
Overall Diameter: 12.26", 311.4 mm
Baffle Hole Diameter: 11.06", 280.9 mm
Number of Mounting Holes: 8
Mounting Holes Diameter: 0.25", 6.4 mm
Mounting Hole BCD: 11.71", 297.4 mm
Depth: 4.44", 112.8 mm
Net Weight: 7.0 lbs, 3.18 kg
Shipping Weight: 9.0 lbs, 4.08 kg
T/S PARAMETERS
Fs: 111.0 Hz
Re: 7.36 ohms
Le: 0.55 mH
Qms: 15.07
Qes: 1.09
Qts: 1.02
Vas: 29.61 L, 1.05 cuft
Vd: 25.9 cc
Cms: 0.07 mm/N
BL: 11.95 Tm
Mms: 30.0 grams
EBP: 101.0
Xmax: 0.47 mm
Sd: 552.0 cm2

CONSTRUCTION
-Copper voice coil on polyimide voice coil former
-Ferrite magnet with non-vented core
-Pressed steel basket
-Paper cone with paper cone edge
-Zurette dust cap

 Other Details

Impedance:
8 ohm
Series:
Legend
Size:
12"
Material:
Ceramic
Rating:
50W-100W
