Product Description
Recommended for professional bass guitar applications in a sealed or vented enclosure. Works well in single or multi driver designs.
| SPECIFICATIONS Nominal size: 10", 254.0 mm Nominal Impedance: 8 ohms Power: 200w rms, 400w program Freq. Response: 35.0 Hz-2.0 kHz Sensitivity: 91.8 db 1w/1m Magnet Weight: 38.0 oz Gap Height 0.312", 7.90 mm Voice Coil Diameter 2.0", 51 mm MOUNTING INFORMATION Recommended Enclosure Volume - Sealed: Acceptable - Vented: Acceptable Overall Diameter: 10.08", 256 mm Baffle Hole Dia: 9.18", 233.2 mm Number of Mounting Holes: 8 Mounting Holes Dia: 0.25", 6.4 mm Mounting BCD: 9.66", 245.4 mm Depth: 4.25", 108 mm Net Weight: 8.9 lbs, 4.04 kg Shipping Weight: 9.1 lbs, 4.13 kg |
T/S PARAMETERS Fs: 35.0 Hz Re: 5.59 ohms Le: 0.83 mH Qms: 5.36 Qes: 0.47 Qts: 0.43 Vas: 91.2 L, 3.22 cuft Vd: 207.4 cc Cms: 0.54 mm/N BL: 10 Tm Mms: 38 grams EBP: 75 Xmax: 6.2 mm Sd: 334.5 cm2 Xlim: 10 mm CONSTRUCTION -Copper voice coil on polyimide voice coil former -Ferrite magnet -Pressed steel basket -Paper cone with cloth cone edge -Zurette dust cap |
